Search and Replace Excel Values

Finding and replacing values while working with big Excel spreadsheets can be a time-consuming and tiring task. Simplify Excel handling and decrease searching time using Robomotion's Excel nodes.

What Search and Replace Excel Values can do

• Build Default Path (Core.Programming.Function) — sets msg.fixtures_dir and msg.sample_xlsx (…/fixtures/sample.xlsx).
• Four Input Dialogs (Core.Dialog.InputBox, all titled Search and replace Excel values):
  • Text to find: (default Istanbul) → msg.text_to_find.
  • Text to replace with: (default Izmir) → msg.new_text.
  • File path (default msg.sample_xlsx) → msg.selected_file.
  • Mode all / first (default all) → msg.rename_function.
• Validate (Core.Programming.Function, outputs: 2) — requires a non-empty msg.text_to_find and an .xls*/.csv file; normalises msg.rename_function to first or all; otherwise Core.Flow.Stop.
• Open Excel (Robomotion.MicrosoftExcel.OpenExcel, optVisible: true) → msg.excel_app_id.
• Search (Robomotion.MicrosoftExcel.SearchSheet, sheetSelection: Active-Sheet, searchTerm: msg.text_to_find) → msg.found_cells.
• Pick Cells To Replace (Core.Programming.Function) — msg.cells_to_replace is the full array or just the first match based on msg.rename_function.
• Loop via Core.Flow.Label + Core.Programming.ForEach over msg.cells_to_replace → msg.current_cell:
  • Extract Cell Address (Core.Programming.Function) normalises the item (string, .address, .Cell, or {column,row}) into msg.cell_address.
  • Replace Value (Robomotion.MicrosoftExcel.SetCellValue, mod1: string, continueOnError: true) writes msg.new_text at msg.cell_address.
  • Core.Flow.GoTo back to the loop label.
• On loop exit: Save (Robomotion.MicrosoftExcel.SaveExcel), Close (Robomotion.MicrosoftExcel.CloseExcel), then a Done! info dialog and Core.Flow.Stop.

Behind the scenes

• SearchSheet runs with sheetSelection: Active-Sheet, so the search is limited to whichever sheet is active when Excel opens the file.
• Replace Value uses continueOnError: true so a single protected/locked cell doesn't abort the whole loop.
• Extract Cell Address handles multiple shapes of SearchSheet output because the package has returned different formats across versions; normalising to a plain A1-style string keeps SetCellValue happy.
• Replacement writes the whole msg.new_text as a string (mod1: string) — partial, case-sensitive matching is not performed; each hit cell is fully overwritten.
