Consolidate Excel Reports

Large-scale reporting is a typical process across many businesses and organizations. Robomotion makes gathering data and creating reports a fast and fully automated task.

What Consolidate Excel Reports can do

• Download Fixtures subflow, then Init Combined builds msg.fixtures_dir, msg.combined_table = null, and msg.output_path = <fixtures>/Consolidated Report.csv.
• Get Excel Files Details subflow populates msg.file_list and msg.recipient_email; Validate List (Core.Programming.Function, outputs: 2) short-circuits to Core.Flow.Stop when either is missing.
• Core.Flow.Label + Core.Flow.GoTo drive a loop around a Core.Programming.ForEach over msg.file_list (msg.current_file); the Read and Append subflow merges each workbook's rows into msg.combined_table.
• Serialize Combined CSV (Function) flattens msg.combined_table into msg.consolidated_csv; Core.FileSystem.WriteFile writes it to msg.output_path; Build Attachments sets msg.attachments = [msg.output_path] and msg.retry_count = 0.
• Robomotion.MicrosoftOutlook.SendMail sends the CSV to msg.recipient_email; a Core.Trigger.Catch retries once after a 5s Core.Programming.Sleep, then stops failed. Success ends with a Message Box showing the save path and recipient.

Behind the scenes

• Robomotion.MicrosoftOutlook.SendMail is flaky on the first call if Outlook hasn't finished initialising — the single retry with a 5s sleep absorbs that cold-start window.
• Outlook is intentionally left running after the send so the user can inspect the Sent folder; no explicit close node.
